| No. |
ITEMS |
SRP (RM) |
|
No. |
ITEMS |
SRP (RM) |
|
No. |
ITEMS |
SRP (RM) |
| 1 |
SPOOL PLATE |
|
|
22 |
SPRING GUIDE |
|
|
43 |
BODY COVER BEARING |
|
| 2 |
SPOOL CLICK RING |
|
|
23 |
SPRING |
|
|
44 |
DRIVE GEAR |
|
| 3 |
CLICK SPRING SEAT |
|
|
24 |
BAIL ASSEMBLY |
|
|
45 |
BODY BALL BEARING |
|
| 4 |
BALL BEARING |
|
|
25 |
MAIN SHAFT |
|
|
46 |
ANTI REVERSE LEVER KNOB SCREW |
|
| 5 |
LINE BLOCK RING |
|
|
26 |
ROTOR WASHER |
|
|
47 |
ANTI REVERSE LEVER KNOB |
|
| 6 |
O RING 4.2:1 |
|
|
27 |
ONE WAY FIXED SCREW |
|
|
48 |
ANTI REVERSE LEVER |
|
| 7 |
LINE BLOCK RING GASKET A |
|
|
28 |
BALL BEARING PLATE |
|
|
49 |
ANTI REVERSE LEVER SPRING |
|
| 8 |
LINE BLOCK RING BUSHING |
|
|
29 |
DUST COVER |
|
|
50 |
ONE WAY BALL BEARING |
|
| 9 |
ROTOR NUT |
|
|
30 |
BALL BEARING |
|
|
51 |
BODY |
|
| 10 |
ROTOR FIXED GASKET |
|
|
31 |
BEARING BUSHING |
|
|
52 |
HANDLE CAP WASHER |
|
| 11 |
ROLLER SCREW |
|
|
32 |
ONE WAY BALL BEARING |
|
|
53 |
HANDLE CAP WASHER |
|
| 12 |
ROTOR |
|
|
33 |
PINION GEAR |
|
|
54 |
SPOOL |
|
| 13 |
LINE ROLLER BALL BEARING |
|
|
34 |
OSCILLATION SLIDER SCREW |
|
|
55 |
DRAG WASHER |
|
| 14 |
LINE ROLLER |
|
|
35 |
OSCILLATION SLIDER SCREW |
|
|
56 |
DRAG ASSEMBLY |
|
| 15 |
LINE ROLLER WASHER |
|
|
36 |
GUIDE SHAFT |
|
|
57 |
SPOOL STOP RING |
|
| 16 |
BAIL ARM |
|
|
37 |
OSCILLATION GEAR A |
|
|
58 |
DRAG KNOB ASSEMBLY |
|
| 17 |
LINE ROLLER SCREW |
|
|
38 |
OSCILLATION GEAR BALL BEARING |
|
|
59 |
HANDLE ASSEMBLY |
|
| 18 |
SCREW |
|
|
39 |
OSCILLATION GEAR BALL BEARING |
|
|
591 |
HANDLE KNOB |
|
| 19 |
COVER SCREW |
|
|
40 |
OSCILLATION GEAR SCREW |
|
|
592 |
HANDLE KNOB |
|
| 20 |
BAIL ARM COVER |
|
|
41 |
BODY COVER |
|
|
593 |
HANDLE KNOB BALL BEARING B |
|
| 21 |
LEVER |
|
|
42 |
BODY COVER SCREW |
|
|
594 |
HANDLE KNOB SHAFT |
|
|
|
|
|
|
|
|
|
595 |
HANDLE KNOB COVER |
|
