Brand

Size

800PG, 2000PG, 3000PG, 4000PG, 5000PG, 800HG, 2000HG, 3000HG, 4000HG, 5000HG, 3000XG, 4000XG, 5000XG

SizeLine Capacity (mm/m)Gear RatioBall BearingMax Drag (kgs)SRP (RM)
800 PG0.165/180 0.205/150 0.235/1205.2:111+110334.00
2000 PG0.205/180 0.235/150 0.260/1205.2:111+112348.00
3000 PG0.235/200 0.260/160 0.285/1205.2:111+116361.00
4000 PG0.260/200 0.285/180 0.310/1505.2:111+122374.00
5000 PG0.285/200 0.310/170 0.335/1405.2:111+125389.00
800 HG0.165/180 0.205/150 0.235/1206.2:111+18334.00
2000 HG0.205/180 0.235/150 0.260/1206.2:111+110348.00
3000 HG0.235/200 0.260/160 0.285/1206.2:111+114361.00
4000 HG0.260/200 0.285/180 0.310/1506.2:111+120374.00
5000 HG0.285/200 0.310/170 0.335/1406.2:111+122389.00
3000 XG0.235/200 0.260/160 0.285/1207.2:111+112382.00
4000 XG0.260/200 0.285/180 0.310/1507.2:111+118395.00
5000 XG0.285/200 0.310/170 0.335/1407.2:111+120409.00
Feature :
-Metal body
-Precision Calculation Transmission System
-Forged Machined Cut Aluminum Spool
-Carbon Fiber Drag Washer
-Powerful Drag System
-Corrosion Resistant Thick Aluminum Bail Arm
-Machined Cut Aluminum Power Handle And Handle Knob
-11+1 Japan Made Ball Bearing
No.ITEMSSRP (RM)No.ITEMSSRP (RM)No.ITEMSSRP (RM)
100BODY101BODY COVER
102BODY CAP8.00103BODY CAP8.00
105COVER8.00106ANTI-REVERSE SPRING3.00
107ANTI-REVERSE CAM3.00108ANTI-REVERSE LEVER3.00
109ONE-WAY HOLDEER8.00110PLATE6.00
111ONE-WAY SPRING3.00112DRIVE GEAR30.00
114PINION GEAR27.00115OSCILLATING GEAR17.00
118SLIDER15.00119MAIN SHAFT18.00
120STABILIZER BAR6.00121MAIN SHAFT BASE3.00
122MAIN SHAFT BASE3.00123SPOOL HOLDER15.00
124SPOOL HOLDER PIN3.00126H/RETAINNER6.00
127ROTOR NUT12.00128BEARING RETAINER8.00
129SPOOL SPRING6.00130SPOOL SPRING BASE6.00
131HANDLE SCREW CAP15.00132ONE-WAY CLUTCH25.00
200ROTOR75.00201ROTOR COVER A10.00
202ROTOR COVER B10.00203BAIL ARM20.00
205BAIL20.00207LINE ROLLER15.00
208CLUMP WEIGHT-209REVERSE LEVER3.00
210BAIL SPRING3.00211BAIL SPRING LEVER3.00
300SPOOL80.00301WASHER3.00
302STAINLESS WASHER3.00303STAINLESS WASHER3.00
304SOUND RING8.00305SOUND RING6.00
306LINE STOP6.00307LINE STOP SPRING6.00
308SPRING3.00400DRAG KNOB20.00
500HANDLESET A : 170.00600HANDLE KNOBSET A
601HANDLE KNOB CAPSET A (3.00)602INSIDE HANDLE KNOBSET A
B10BALL BEARINGSET A (20.00)B11BALL BEARINGSET A (20.00)
S9 SCREWSET A (3.00)S4SCREW3.00
B1BALL BEARING20.00B2BALL BEARING20.00
S1SCREW3.00E1WASHER3.00
S2SCREW3.00S4SCREW3.00
E3WASHER3.00B7BALL BEARING20.00
B5BALL BEARING20.00S3SCREW3.00
B3BALL BEARING20.00B6BALL BEARING20.00
B8BALL BEARING20.00S5SCREW3.00
S6SCREW3.00S7SCREW3.00
S8SCREW3.00B9BALL BEARING20.00
E4WASHER3.00S10SCREW3.00
E2WASHER3.00B4BALL BEARING20.00
S5SCREW3.00
